small aluminum extrusion machine
NO. | Item | Type | QTY |
1 | Hydraulic system working pressure | 21Mpa |
|
2 | Extrusion Pressure | Main Cylinder 633T |
|
Lateral Cylinder 51.5T |
| ||
3 | Lateral cylinder return force | 16T |
|
4 | Locking force of container | 51T |
|
5 | Shear pressure | 32T |
|
6 | Extrusion working speed(maximum) | 8.8mm/s |
|
7 | Master plunger fast forwarding speed | 315mm/s |
|
8 | Master plunger fast backward speed | 348mm/s |
|
9 | Closing speed of container | 136mm/s |
|
10 | Open speed of container | 83mm/s |
|
11 | Shear down speed | 216mm/s |
|
12 | Shear up speed | 442mm/s |
|
13 | The inner hole range of extrusion tube | ID Φ85-115 |
|
L 500mm |
| ||
14 | The dimension range of aluminum bar | IDΦ80-Φ110 |
|
L 450mm |
| ||
15 | The total power of motor | 55KW |
|
16 | Heating power for extrusion tube | T 1.2KW*15=18KW |
|
17 | Operation Mode | Manual or automatic single stoke |
|
18 | External dimension(L*W*H) | 7m*2.8m*3.2m |
